Operators¶

What Operators Are¶

Semantically, operators are the steps a pipeline takes to turn an input into an output.

The pipeline itself does not have any task or workflow specific logic. The pipeline is the framework that runs operators in order, threads context, and layers tooling on top of those steps. If a pipeline converts an image into detections, or a text string into a list of tokens, the interesting logic lives in the operators:

• decode the input
• normalize it
• run inference
• extract tensors
• project coordinates
• convert to the final output object

In that sense, a pipeline is closer to a harness for operators than to the operators themselves.

How Operators Look In Code¶

Concretely, an operator is anything the pipeline can execute as one step.

For simple local logic, a plain function is enough:

def strip_text(text: str) -> str:
    return text.strip()

For reusable configured logic, use a class with __call__. Decorating it with @Operator makes it self-describing in repr() and describe():

from ml_pipes.core import Operator


@Operator
class Prefix:
    def __init__(self, prefix: str) -> None:
        self.prefix = prefix

    def __call__(self, text: str) -> str:
        return f"{self.prefix}{text}"

repr(Prefix("tag: "))
# Prefix('tag: ')

Pipelines can mix both forms freely:

from ml_pipes.core import Pipeline

pipeline = Pipeline([strip_text, Prefix("tag: ")])
assert pipeline("  hello  ") == "tag: hello"

What Operators Are Made Of¶

Most reusable operators have four parts the pipeline cares about:

@Operator
class Prefix:
    def __init__(self, prefix: str) -> None:
        self.prefix = prefix

    def __call__(self, text: str) -> str:
        return f"{self.prefix}{text}"

• Input is the __call__ parameter annotation. Here, the operator accepts str.
• Output is the __call__ return annotation. Here, the operator produces str.
• Config is the constructor state captured when you build the operator. Here, that is prefix.
• Static validation rule is the boundary the validator reads from the operator definition. In the simple case, __call__ annotations are enough: the validator can see that this operator accepts str and returns str.

When that static shape is not enough, define resolve_contract(...). Use it for operators whose real boundary depends on the current upstream type, stored context, or tuple routing. Most normal transform operators do not need it.

Special Operator Shapes¶

Most operators are plain functions or @Operator classes with a normal __call__ boundary. A few superclass patterns exist because some operators participate in framework mechanisms beyond a normal transform:

• Reach for the ContextOp[In, Out] superclass when the operator needs to read or write pipeline context while still presenting one explicit pipeline boundary.
• When the behavior cannot be expressed as one operator's transform and instead defines how a bounded group of operators should execute together, read regions.md. Region operators are implemented through the RegionOpener[In, BodyIn] and RegionCloser[BodyOut, Out] superclasses.
• Reach for the SideEffectOp[T] superclass when an operator should pass the value through unchanged while observing, logging, drawing, or saving.

These are still operators, but they participate in extra execution mechanics. Read architecture.md for how context and regions fit into pipeline execution, and regions.md for region semantics and examples.

Features Built On Operators¶

The features below are not provided by the @Operator decorator itself. They work because the framework treats operators as explicit pipeline boundaries with meaningful input, output, and step identity. When those boundaries are chosen well, composition, validation, description, inspection, tracing, and benchmarking all become useful.

The examples below use the same tiny operator chain:

from ml_pipes.collectors import PrintCollector
from ml_pipes.core import Operator, Pipeline


def strip_text(text: str) -> str:
    return text.strip()


@Operator
class Lowercase:
    def __call__(self, text: str) -> str:
        return text.lower()


@Operator
class SplitWords:
    def __init__(self, delimiter: str) -> None:
        self.delimiter = delimiter

    def __call__(self, text: str) -> list[str]:
        return text.split(self.delimiter)

Composition¶

Composition is the core behavior: the output of one operator becomes the input to the next operator. The pipeline does not need task-specific logic here; it just runs one operator, takes the returned value, and feeds it to the next.

pipeline = Pipeline([strip_text, Lowercase(), SplitWords(delimiter=" ")])
pipeline("  Hello World  ")
# ['hello', 'world']

Validation¶

Validation checks whether one operator's output boundary is compatible with the next operator's input boundary.

pipeline = Pipeline([strip_text, Lowercase(), SplitWords(delimiter=" ")])
contract = pipeline.validate(strict=True)
print(f"Input: {contract.input_type}, Output: {contract.output_type}")

Input: <class 'str'>, Output: list[str]

Description¶

Because a pipeline is a list of operators, the operator chain is directly describable.

pipeline = Pipeline([strip_text, Lowercase(), SplitWords(delimiter=" ")])
pipeline.describe()

Pipeline([
  strip_text,
  Lowercase(),
  SplitWords(delimiter=' '),
])

Tracing¶

Tracing reports latency per operator step.

pipeline = Pipeline([strip_text, Lowercase(), SplitWords(delimiter=" ")])
pipeline.set_tracing(PrintCollector())
pipeline("  Hello World  ")
pipeline.set_tracing(None)

  0:strip_text                      0.01ms  (21.6%)
  1:Lowercase                       0.01ms  (43.1%)
  2:SplitWords                      0.01ms  (17.4%)
  total                             0.03ms

Inspection¶

Every operator establishes a data boundary. Inspection builds on tracing at those boundaries: tracing records a span for each operator, and Pipeline.inspect() captures that operator's output in the span. The resulting InspectionResult shows how values move through the operator chain.

from ml_pipes.inspection import PipelineInspector

result = pipeline.inspect(value)
PipelineInspector().show(result)

For setup, rendering, and custom formatters, see inspection.md.

Benchmark¶

Benchmarking repeats the pipeline over many runs and aggregates latency at the same operator boundaries tracing uses.

from ml_pipes.benchmark import Benchmark, MeasurementConfig

result = Benchmark(
    pipeline,
    input_fn=lambda: ("sample", "  Hello World  ", None, None),
    measurement=MeasurementConfig(runs=5, warmup=1, percentiles=(0.50,)),
).run()

print(result.to_table())

operator            mean        p50     stddev        min        max
--------------------------------------------------------------------
total              0.04       0.03       0.00       0.03       0.04
0:strip_text       0.01       0.01       0.00       0.01       0.01
1:Lowercase        0.01       0.01       0.00       0.01       0.02
2:SplitWords       0.01       0.01       0.00       0.01       0.01
--------------------------------------------------------------------
runs: 5  (all values in ms)

Design Principles¶

Operators should satisfy a few hard constraints so they stay safe to compose, swap, and reason about.

Atomic. One meaningful pipeline boundary, not a whole workflow.

Stateless. Keep only construction-time config (name, axis, threshold, prefix, etc.), never hidden runtime memory.

Effect-explicit. If an operator touches context, opens a region, performs a side effect, or crosses a runtime boundary, that should be obvious in its type and behavior.

Reusable at the right layer. Put broadly reusable behavior in shared operators; keep project glue and experiments in local pipeline code.

Composable. Operators should be easy to insert, remove, reorder, validate, inspect, trace, and benchmark as standalone boundaries.

Best Practices For Creating Operators¶

Scope¶

• Each operator should do one meaningful transformation or control-flow step. If the behavior is bigger than that, compose multiple operators instead of fusing a whole workflow into one.
• Break operators where you want the pipeline boundary to be. If you want validation, inspection, tracing, or failures to stop at a specific point, make that point its own operator instead of fusing past it.
• Start with the simplest form that fits. Use a plain function for short local transforms. Move to a class with @Operator when the logic needs configuration, reuse, or clearer description output.

Config¶

• Operator config is a pipeline-build-time value. Put it in __init__, and normalize and validate it once at construction time.
• Config is static. If the same input under the same config produces different output over time because the operator remembered previous calls, that is hidden state, not config.

Runtime Boundary¶

• Use the invocation value for data that can change from one pipeline call to the next without rebuilding the pipeline.
• Do not pass operator config as per-invocation payload. If a value is really part of how the operator is configured, put it in __init__.
• Declare accurate __call__ annotations so the operator's runtime boundary is explicit.
• Use generics and TypeVar when the operator preserves or transforms the relationship between input and output types.
• Avoid Any in __call__ annotations unless the boundary is genuinely impossible to express more precisely.

Input¶

• Define an input boundary that makes sense for the operator's actual job.
• Avoid passing a large payload to an operator when it only needs one small part of it. Use Pick or Select to pass only what the operator needs, which usually makes the operator more reusable.
• When an operator truly consumes multiple separate values, prefer multiple positional inputs over wrapping everything into one input object. The pipeline can unpack fixed-length tuple values automatically, which usually makes the operator boundary easier to read.

Output¶

• Return a single value when the operator produces one semantic result.
• For ordinary transforms, treat the input as immutable and return a new value instead of mutating the input in place.
• Use a fixed-length tuple when the operator returns multiple values that are small, short-lived, and positionally obvious to the next few steps. This pairs naturally with the multi-input pattern described in the input rules above.
• Remember that a fixed-length tuple is structural in ml-pipes. Returning tuple[A, B] publishes two positional pipeline values, and tuple-routing operators such as Pick and Recall will act on that structure. If the tuple is semantically one payload, wrap it in a dedicated object instead of returning the raw tuple.
• Use a dedicated dataclass when fields have high cohesion, represent one named result, and are usually used together by name.
• A useful pattern is the carry-forward tuple: return the original value together with a new derived value when later pipeline steps are expected to keep using both. Rendering is a good example: an operator can return (rendered_image, registry) so later steps can save the image while still rendering, filtering, or logging named prediction tensors in different ways.
• In-place mutation is acceptable when the payload is already mutation-oriented and that keeps the pipeline clearer.
• Use a registry-style payload when many operators cooperatively read and write named intermediate slots, as with tensor.TensorRegistry or torch.TensorRegistry.

Naming And Aliases¶

• Choose one primary name for each operator surface based on what the operator does.
• Do not name an operator relative to other operators or to one specific pipeline shape. Operators can appear in any position and in many different pipelines.
• Use aliases when a domain-specific spelling makes a common use case read better.
• Treat aliases as alternate spellings of the same operator, not as separate operators with different semantics.

Static Verification¶

• Define resolve_contract(...) only when normal annotations cannot express the real boundary precisely, such as upstream-type-dependent, context-aware, or tuple-routing operators.
• Put only boundary logic inside resolve_contract(...). Checks like simple config validation belong in __init__; use resolve_contract(...) only for checks that depend on boundary information.
• Use the upstream type effectively to compute an accurate output type. If the operator preserves or transforms part of the incoming shape, reflect that in the returned contract instead of discarding it.
• Return the narrowest contract you can justify. Do not fall back to Any unless the boundary is genuinely impossible to express more precisely.
• Keep resolve_contract(...) aligned with runtime behavior. If __call__ or apply() changes what the operator actually accepts or returns, resolve_contract(...) should change with it.

Special Operators¶

• Reach for the SideEffectOp[T] superclass when the operator should behave like T -> T and its semantic job is to observe, log, draw, or save rather than transform the flowing value.
• Reach for the ContextOp[In, Out] superclass when the operator genuinely needs to read from or write to pipeline context as part of its behavior. Do not extend ContextOp just to read one specific key from context. If the operator has a specific dependency, define it in the operator signature and let pipeline composition provide it explicitly.
• Reach for the region mechanism (explained in regions.md) when the behavior cannot be expressed as one operator's transform and instead defines how a bounded group of operators should execute together.

Errors And Verification¶

• Error messages should be direct and local to the operator that detects the problem.
• Verify the operator inside a real pipeline. validate() checks its boundary, inspect() shows what value flows through it, and tracing or benchmarking can be added once correctness is already established.

Operator Packages¶

So far this page has focused on what operators are and how to create them. In practice, many reusable operators already exist, so most users should start from packages.md and then check the linked package reference for the operators they need.

Start from ml_pipes.standard for shared generic building blocks such as routing, context, regions, and data-preparation work.

Example: if postprocess is still tensor-shaped, start from the tensor package and its reference in packages/tensor/docs/reference.md.
